ZF 400 Series User Manual

Technical data
16
EN_3224.758.102d_2021_12
2 Technical data
• * ) reverse transmission without accessories; (for further details, see chapter "Oil level inspection" (p. 23));
• ** ) reference rpm: 1500.
The values must be measured using holes (5) and (15), indicated on page "Main subgroups" (p. 10).
2.1 Types of oil
Use the following oils (refer to the ZF-TLM 04 standard, edition 02/2009):
2.1.1 Lubricant class 04A
Single-grade engine oils (API CD/CE/CF-4/CF/CG-4/CH-4/CI-4/SF/SG/SH/SJ/SL or ACEA categories, A/B/E)
Viscosity classes: SAE 30, in warm countries or when the temperature in the oil pan exceeds +80°C SAE 40 is also
accepted.
2.1.2 Lubricant class 04B
Single-grade engine oil
Viscosity class: SAE 30, in warm countries or when the temperature in the oil pan exceeds +80°C, SAE 40 is also ac-
cepted.
2.1.3 Lubricant class 04C
Multi-grade engine oil
Viscosity classes: SAE 5W-40 / 10W-40 / 15W-40
TYPE *OIL QUANTITY (DM
3
)
PUMP FLOW RATE (L/
MIN AT 1000 RPM)
**OPERATING PRES-
SURE (BAR)
TEMPERATURE (°C)
ZF 400 A 8,5 ÷ 9,5 19 23 ÷ 24 40 ÷ 80
ZF 400 IV 9 ÷ 10 19 23 ÷ 24 40 ÷ 80
ZF 400 V 12 ÷ 14 22 23 ÷ 24 40 ÷ 80
ZF 400 11 ÷ 12 19 23 ÷ 24 40 ÷ 80
NOTE:
We suggest installing a pressure indicator (range 0-50 bar) on hole (15) and an oil temperature sensor on hole (5).
All commercial products formulated with mineral oil that meet the above-mentioned specifications are allo-
wed. No product list is available.
As for gearboxes certified by DNV, class 04A lubricants cannot be used. Therefore, these gearboxes must be
filled with class 04B or 04C lubricants.
WARNING
WARNING

ZF 400 Series Specifications

General

Type	Marine Transmission
Series	400 Series
Manufacturer	ZF
Application	Marine
Max Input Power	Varies by model (Consult ZF specifications)
Rated power (hp)	Varies by model (Consult ZF specifications)
Max Input Speed	Varies by model (Consult ZF specifications)
Gear Ratios	Varies by model (Consult ZF specifications)
Weight (kg)	Varies by model (Consult ZF specifications)
Weight (lbs)	Varies by model (Consult ZF specifications)
Mounting	Varies by model (Consult ZF specifications)
Housing Material	Aluminum
Oil Capacity (L)	Varies by model (Consult ZF specifications)
Oil Capacity (US qt)	Varies by model (Consult ZF specifications)
Cooling System	Integrated oil cooler (optional external cooler)
