ZF 400 Series User Manual

Introduction
7
EN_3224.758.102d_2021_12
1.3 Responsibilities
The customer/operator is responsible for the maintenance checks described in this manual to ensure the proper ope-
ration of the reverse transmission in fully safe conditions.
1.3.1 Manufacturer's address and contact info
All gearboxes supplied by ZF Padova S.r.l. are accompanied by the relative operating manual.
Further copies of this manual or of other technical documentation can be obtained from:
ZF Padova S.r.l.
Via Penghe 48,
35010 Caselle di Selvazzano (PD), Italy
Tel. +39 049 8299485
Fax +39 049 8299560
1.4 Reverse transmission identification
The identification plate is affixed to the reverse transmission. Before proceeding with the installation, we recommend
reading the instruction manual.
For important information regarding technical reliability and safety, the following conventions have been adopted:
NOTE:
The notes contain important information, to which the user must pay careful attention.
SERIAL No
RATIO
TYPE
OIL TYPE
OIL CHANGE: after first 50 hours of operation and every
1000 hours or 12 months, wichever occurs first.
CHECK OIL LEVEL WEEKLY
OIL
CAPACITY (dm
3
)
CLUTCH OIL
PRESSURE(bar)
CUSTOMER No
MASS DRY (Kg)
PART LIST No
ContinousMediumLightPleasure
Fig. 1

ZF 400 Series Specifications

General

Type	Marine Transmission
Series	400 Series
Manufacturer	ZF
Application	Marine
Max Input Power	Varies by model (Consult ZF specifications)
Rated power (hp)	Varies by model (Consult ZF specifications)
Max Input Speed	Varies by model (Consult ZF specifications)
Gear Ratios	Varies by model (Consult ZF specifications)
Weight (kg)	Varies by model (Consult ZF specifications)
Weight (lbs)	Varies by model (Consult ZF specifications)
Mounting	Varies by model (Consult ZF specifications)
Housing Material	Aluminum
Oil Capacity (L)	Varies by model (Consult ZF specifications)
Oil Capacity (US qt)	Varies by model (Consult ZF specifications)
Cooling System	Integrated oil cooler (optional external cooler)
