Zhiyun CRANE 3S User Manual

23
STEP 1 STEP 2
STEP 3 STEP 4
STEP 5 STEP 6
Motor Fine-tuning
① Please refer to the six-side calibration steps below. After the calibration is
completed, please restart the stabilizer.
② In simple terms, six-side calibration is to place all six sides of the camera
mounting plate in vertical to a level surface respectively
3. Six-side calibration via OLED display guide:
Connect the stabilizer with SmartSling Handle, power on the stabilizer and enter standby
mode, then press menu and rotate the dial to "calibration" option. Single press Right to
confirm the selection, and single press "yes" to start. Conduct the steps appearing on
the stabilizer display screen. After the calibration is completed, a " √ " mark will appear
on the display screen.
According to the method introduced in "APP Operations", please connect the stabilizer
with APP, and enter "Settings" and select "motor calibration", then set the fine-tuning
value of the tilt axis and roll axis according to actual needs.
Calibration and Firmware Upgrade

Zhiyun CRANE 3S Specifications

General

Payload Capacity	6.5 kg
Battery Runtime	12 hours
Battery Capacity	2600mAh
Charging Time	4 hours
Pan Angle Range	-360° to +360°
Motor Type	Brushless
Bluetooth	Yes
Wi-Fi	Yes
Roll Angle Range	-90° to +90°
Operating Temperature	-10℃ to 45℃
Control Interface	Via App
Compatible Cameras	DSLR, Mirrorless
Follow Modes	Pan Follow, Lock, Follow, POV, Vortex, Go
Power Supply	Rechargeable Li-ion battery
