8.3.6 Read values out of member
MB Input Register 31, Address: i30 = Event
MB Input Register 31, Address: i30 Event
Event log entry according to Register error status (i12).
Selection of entry 1 - 10 by entering command code 7500 - 7509.
Access R
minimal value 0
maximum value 65535
Bit [15:0] Error status
MB Input Register 13, address: i12 = error status
MB Input Register 13, Address: i12 Error status
Display Error status
Access R
minimal value 0
maximum value 65535
Bit [15] 1: COM error (Watchdog)
Bit [14] 1: Motor Start
Bit [13] 1: Temperature error (
R12.12, R12.13)
Bit [12] 1: Safety Shutdown (max. electronic Current, from FW13)
Bit [11] 1: Sinefilter (only Fcontrol)
Bit [10] 1: PEAK CURRENT (from FW10)
Bit [9] 1: MOTOR BLOCKED
Bit [8] 1: HALLSENSOR
Bit [7] 1: TB (reserved for PMblue etc.)
Bit [6] 1: LINE FAULT
Bit [5] 1: UIN LO (from FW10)
Bit [4] 1: UIN HI (from FW10)
Bit [3] 1: UZK LO
Bit [2] 1: UZK HI
Bit [1] 1: EARTH TO GROUND FAULT
Bit [0] 1: IGBT FAULT
MB Input Register 15, Address: i14 = Speed
MB Input Register 15, Address: i14 Speed: 1/min
Display actual speed
Access R
minimal value 0
maximum value 65535
Bit [15:0] Decimal value 0 - 65535
