FSDM40M
(308318)
40.0
34.0
(31.5)
50 50 790 29.4
FSDM50M
(308320)
50.0
47.5
(43.2)
50 63 910 32.6
{1} Rated current output
current indication rating plate @ rated voltage, @ rated temperature (cos φ 0.8 at the output).
{2} At rated voltage (cos φ 0.8 at the output), values for different specifications on request.
{3} Max. supply side line fuse according to EN 60204-1 classification VDE0113 chapter 1.
Line voltage* 3 ~ 208...480 V (-15 ... +10 %), 50/60 Hz
Rated voltage 400 V
Maximal output voltage approx. 95 % from U
line
Maximal output frequency 50 Hz (1 - 120 Hz) **
Edgefrequency 48.5 Hz (1 - 120 Hz) **
U/f-characteristic curve quadratic (linear) **
Switching frequency 16 kHz
Rampup time FSDM2.5...16: 20 sec (1 - 250 sec) **
FSDM22...50: 40 sec (1 - 250 sec) **
Rampdown time FSDM2.5...16: 20 sec (1 - 250 sec) **
FSDM22...50: 40 sec (1 - 250 sec) **
Current limit 120 % (100 - 130 %) **
Power factor > 0.9
Input resistance for speed setting
signal
0...10 V Input: R
i
= 300 kΩ
0...20 mA input: R
i
= 500 Ω
PWM input U
in
14...28 V:
R
i
@ 14 V = 21.6 kΩ
R
i
@ 28 V = 3.6 kΩ
Digital input “D1” Input resistance: R
i
approx. 4 kΩ
Voltage range high level: 10....30 V DC
Voltage range low level: 0....4 V DC
Voltage supply for external devices +24 V ± 20 %, I
max
70 mA
Power loss in standby approx. 3 W
Output 10 V I
max
10 mA (short-circuit-proof)
Max. contact rating of the relay 2 A / 250 V AC
Max. permissible ambient tempera-
ture
55 °C
Min. permissible ambient tempera-
ture
0 °C (if mains voltage is not switched off up to -20 °C)
To avoid condensation the device must be continuously energized due to
the application of heat, with interruptions such that cooling to the point of
condensation does not occur.
Permissible temperature range for
storage and transport
-30...+80 °C (FSDM22: -30... +70 °C)
Permissible installation height 0...4000 m amsl
≤ 1000 m: no limitation
> 1000 m: max. permissible output current = current indication name plate
minus 5 % / 1000 m
> 2000 m: max. permissible line voltage = max. voltage indication name
plate minus 1.29 % / 100 m
Permissible rel. humidity 85 % no condensation
Electromagnetic compatibility for the
standard voltage 230 / 400 V ac-
cording to DIN IEC 60038
Interference emission EN IEC 61000-6-3 (domestic household applica-
tions)
Interference immunity EN IEC 61000-6-2 (industrial applications)
Harmonics current According to EN 61000-3-2 (see Electrical installation / Harmonics current)
Max. leakage current according to
the defined networks of
DIN EN 60990
FSDM2.5/5/8M < 3.5 mA
FSDM10/22/32/40/50M > 3.5 mA
FSDM16M (depending on applied mains voltage)
< 3.5 mA @ < 480 V
≥ 3.5 mA @ ≥ 480 V
Operating Instructions Fcontrol Basic – model series FSDM2.5..50M Enclosure
L-BAL-E162-GB 2022/02 Index 008 Part.-No.
25/30
