Page 80 MS - SOUND decoders MS440 to MS990 and MN - NON-SOUND decoders MN170 to MN340
CV
Denomination
Range
Default
Description
5.3
#699
Loop info F28
Same as CV #515 but for F28
5.3
#726
Connection 1
sound
0
Sound number for connection 1 (usually defined by sound
project and should not be changed if possible). Within the
documentation of (most of the) sound projects sound
numbers are listed.
5.3
#727
Connection 1 FO
0
Function output to connection 1 which shall be
activated - if the sound is played back. 1 = FO0f, 2 =
FO0r, 3 = FO1, ...
5.3
#728
Connection 2
sound
0
Sound number to connection 2
5.3
#729
Connection 2 FO
0
Function output to connection 2:
1 = FO0f, 2 = FO0r, 3 = FO1, ...
5.3
#730
…
#735
…
0
…
5.3
#736
Conn. 6 sound
0
Soundnumber to connection 6.
5.3
#737
Connection 6 FO
0
Function output to connection 6:
1 = FO0f, 2 = FO0r, 3=FO1, ...
#738
Reed 1 sound
number
Sample number according to sample info for switch in-
put S1
5.3
#739
Switch input sound
S1
0 - 255
=
100, 1-100
%
0
Volume setting for the sound activated with switch input
S1
= 0: full volume, original sound sample volume (same
as 255)
= 1 - 254: reduced volume 1 – 99.5 %
= 255: full volume
#740
Reed 2 sound
number
Sample number according to sample info for switch
input S2
5.3
#741
Switch input sound
S2
0 - 255
0
Volume setting for the sound activated with switch input
S2
#742
Reed 3 sound
number
Sample number according to sample info for switch
input S3
5.3
#743
Switch input sound
S3
0 - 255
0
Volume setting for the sound activated with switch input
S3
#744
Random Sound Z1
Sample number of function sound on Z1
5.3
#745
Function sound Z1
0
Volume setting for sound activated by random
generator Z1
#746
Random sound Z1
- info
Bit3=1: Random sound Z1 may come at standstill
Bit6=1: Random sound Z1 may come when moving
#747
Random Sound Z2
Sample number of function sound on Z2
5.3
#748
Function sound Z2
0
Volume setting for sound activated by random
generator Z2
#749
Random sound Z2
- Loop info
Bit3=1: Random sound Z2 may come at standstill
Bit6=1: Random sound Z2 may come when moving
#750
Random Sound Z3
Sample number of function sound on Z3
5.3
#751
Function sound Z3
0
Volume setting for sound activated by random
generator Z3
#752
Random sound Z3
- Loop info
Bit3=1: Random sound Z3 may come at standstill
Bit6=1: Random sound Z3 may come when moving
#753
Random Sound Z4
Sample number of function sound on Z4
5.3
#754
Function sound Z4
0
Volume setting for sound activated by random
generator Z4
CV
Denomination
Range
Default
Description
#755
Random sound Z4
- Loop info
Bit3=1: Random sound Z4 may come at standstill
Bit6=1: Random sound Z4 may come when moving
#756
Random Sound Z5
Sample number of function sound on Z5
5.3
#757
Function sound Z5
0
Volume setting for sound activated by random
generator Z5
#758
Random sound Z5
- Loop info
Bit3=1: Random sound Z5 may come at standstill
Bit6=1: Random sound Z5 may come when moving
#759
Random Sound Z6
Sample number of function sound on Z6
5.3
#760
Function sound Z6
0
Volume setting for sound activated by random
generator Z6
#761
Random sound Z6
- Loop info
Bit3=1: Random sound Z6 may come at standstill
Bit6=1: Random sound Z6 may come when moving
#762
Random Sound Z7
Sample number of function sound on Z7
5.3
#763
Function sound Z7
0
Volume setting for sound activated by random
generator Z7
#764
Random sound Z7
- Loop info
Bit3=1: Random sound Z7 may come at standstill
Bit6=1: Random sound Z7 may come when moving
#765
Random Sound Z8
Sample number of function sound on Z8
5.3
#766
Function sound Z8
0
Volume setting for sound activated by random
generator Z8
#767
Random sound Z8
- Loop info
Bit3=1: Random sound Z8 may come at standstill
Bit6=1: Random sound Z8 may come when moving
3.17
#800
- #805
Swiss Mapping
Group 14
“A2” reverse
Bits 0 - 3:
1 - 12
14
(FO0f)
15
(FO0r)
Bits 5 - 7:
0 - 7
0
Bits 0 - 3:
Additional function output to be switched ON in reverse
direction provided that both the “F” and “M”-keys are
ON (if bit #7 for the M-key = 1, otherwise F-key ON is
sufficient).
Bits 7, 6, 5 (7 possible values or zero):
Number of the applicable dimming CV. For example:
Bit 5 = 1 means dimming according to CV #508 etc.
3.17
#806
- #811
. . . - Group 15.
. . .
0
. . .
3.17
#812
- #817
. . . - Group 16.
. . .
0
. . .
3.17
#818 -
#823
. . . - Group 17.
. . .
0
. . .
3.12
#830
Braking distance
forward High Byte
0 - 255
0
Supplementary to CV #140:
Extended definition of the Constant Braking Distance:
With CV #830 - #833 a more precise and direction
dependent braking distance can now be set. The factor
compared to CV #141 is 1 to 16.
The braking distance to be defined is calculated from:
(256 * High Byte) + Low Byte.
CVs 830 - 833 are only effective if CV #141 = 0.
3.12
#831
Braking distance
forward Low Byte
0 - 255
0
3.12
#832
Braking distance
backward High
Byte
0 - 255
0
3.12
#833
Braking distance
backward Low
Byte
0 - 255
0
5.3
5.6
#835
Number of
set+keys
Number of set switching keys. These keys are always
located one after the other, beginning with the key
defined in CV #345.
5.6
#836
Motor Start Sound
Bit 0
Bit 0 = 1: Bit 0 = 1: Loco shall not start driving before
Start sound is fully played.
