Large-scale Decoder & Sound Decoder MX695, MX696, MX697, MX699 Page 55
Thyristor control
Volume during
deceleration
Motor sound of
ELECTRIC engines
Volume during heavier decelerations (braking)
Thyristor control
Lowering the volume
at higher speeds
for ELECTRIC
engines
Internal speed step at which the thyristor sound
volume should be reduced. The volume stays at
this reduced level while braking.
By changing CV #158 Bit 6 = 1, the volume will be
raised while braking.
Thyristor control
Volume reduction
curve at higher
speeds
for ELECTRIC
engines
Defines a curve as to how the thyristor sound
should be lowered at the speed step in CV #357.
= 0: no reduction.
= 10: reduced by about 3% per speed step.
= 255: aborts the sound when the speed step
defined in CV #357 is reached.
Thyristor control
Switchover threshold
for second thyristor
sound
for ELECTRIC
engines
Defines a speed step at which a second thyristor
sound for higher speeds is played back; this was
introduced for the sound project “ICN” (Roco OEM
sound)
= 0: no second thyristor sound.
Electric motor sound,
maximum volume
for
ELECTRIC engines
Maximum volume of motor sound.
Electric motor sound,
when sound
becomes audible
for
ELECTRIC engines
Internal speed step at which the motor sound be-
comes audible.
Part of a charachteristic curve with CV’s #298/299.
Electric motor sound,
volume dependent
on speed
for
ELECTRIC engines
Slope of the characteristic curve for speed de-
pendent volume. (curve starts with #297)
See ZSP manual!
Electric motor sound,
Sound pitch
dependent on speed
for
ELECTRIC engines
Slope of the characteristic curve for speed de-
pendent volume. (curve starts with #297)
See ZSP manual!
Electric motor sound,
Volume dependent
= 0: No function
= 1…255: minimal to maximum effect
on speed
for
ELECTRIC engines
Electric motor sound,
Volume dependent
on braking
for
ELECTRIC engines
= 0: No function
= 1…255: minimal to maximum effect
Switchgear sound,
lock-out after start up
for ELECTRIC
engines.
Time in tenths of a second (0 – 25 sec.) the switch
gear sound should be delayed after departure; use-
ful when the first switching step is already part of
the sound sample “idle -> F1”.
The switchgear on some engines (i.e. E10) should
not be heard immediately after start-up but rather
after some time defined here.
= 0: Switchgear is heard immediately at departure.
Electric switch gear
sound
Playback duration for
the switch gear
sound during speed
changes
for ELECTRIC
engines
Time in tenth of a second the switch gear should
be heard during speed changes (adjustable from 0
– 25 sec.).
Effective only if switch gear sound is part of the
sound project.
Electric switch gear
sound
Playback duration for
the switch gear
sound after coming
to a stop
for ELECTRIC
engines
Time in tenth of a second the switch gear should
be heard after the engine comes to a full stop (ad-
justable from 0 – 25 sec.).
= 0: no sound after stop.
Switch gear sound
Playback delay
for ELECTRIC
engines
During rapid successions in speed changes the
switch gear sound would be played back too often.
CV #361: Time in tenths of a second (0 – 25 sec.)
defines minimum delay between multiple play-
backs.
Switch gear sound
Dividing the speed
into shift steps
for ELECTRIC
engines
Number of shift steps to cover the whole speed
range; i.e. if 10 shift steps are programmed, the
switch gear sound is played back at internal speed
step 25, 50, 75… (a total of 10 times)
= 0: synonymous with 5 (5 switch steps over
the whole speed range).
Manual electric brake
key
Defines a function key to manually control the
sound of a “dynamic” or “electric” brake.
The electric brake shall only be heard between the
