COMMISSIONING
Lock level
Fig. 10
The operating mode of the appliance can be restricted. The service menu can be used
to configure the appliance.
Activation of the lock level
• Set required lock level in the service menu (refer to chapter “Service menu” in this
installing instructions).
• Disconnect the appliance from the power supply.
• Move the jumper on the power electronics (PCB) from pin 2 to pin 1 (see figure 10).
• Reconnect the power supply to the appliance.
Deactivation of the lock level
• Disconnect the appliance from the power supply.
• Move jumper from pin 1 to pin 2 (see figure 10).
• Reconnect the power supply to the appliance.
