STEP 7.
Fix the handlebar (39) to the handlebar bracket (32) with
the handlebar adjustment knob (37) the handlebar cover
(36), a flat washer (21), and a separator (38).
Secure the components well.
STEP 8.
Connect the cables protruding from the upper part of the
handlebar bracket (32) with the cables from the computer
(44).
Install the computer (44) on the computer bracket on the
front main frame (1) with cross-head bolts (41).
Congratulations!
You have assembled magnetic bike!
Read the manual carefully before using the bicycle.
ADJUSTMENTS
Resistance adjustment
In order to increase the resistance, turn the resistance knob clockwise. In order to decrease the resistance,
turn the resistance knob counterclockwise.
Handlebar adjustment
Loosen the handlebar adjustment knob. Set the handlebar in the desired position and tighten the knob.
Make sure the handlebar is secured.
Saddle position
Loosen the saddle guide knob. Set the saddle to the desired position and tighten the knob. Make sure the
saddle is secured.
Adjusting pedal straps
Fix the side of the rubber strap with three holes to the internal part of the pedal. Fix the other end to one of
the adjustment opening so that the feet is fixed during training and easy to take out. Repeat for the other
pedal.
MAINTENANCE
Carry out maintenance activities at regular intervals.
The tasks listed below should be carried out at least every 20 hours of operation.
• Check moving parts of the device. If they need lubrication, use a bicycle bearing grease.
• Check the conditions of such parts as bolts and nuts. Make sure they are tight.
