Zipro Hulk RS User Manual

22
EN
PARTS LIST
No.
Description
Quantity
No.
Description
Quantity
1
Main frame
1
35
Bolt M8x16
6
2
Front base
1
36
Connecting cable
1
3
Rear base
1
37
Computer cable
1
4
Bolt M8x90
2
38
Resistance adjustment cable
1
5
Curved washer
4
39
Bolt M8x15
2
6
Nut M8
4
40
Spring washer D8
4
7
Rear base levelling pad
2
41
Flat washer Φ8.2xφ32x2
2
8
Crank
2
42
Bolt ST3.5x13
12
9
Bolt M5x10
4
43A/B
Left handle arm cover
1/1
10A/B
Pedal base rear cover
1/1
4 L/R
Handle arm, left/right
1/1
11
Bolt M10x55
2
45
Curved washer Φ8.5xφ20xr12.5
4
12
Flat washer Φ10.5xφ20x2
4
46L/R
Left/right handle
1/1
13
Pedal base to crank connector
2
47
Bolt M8x45
4
14
Nut M10
3
48
Handle foam
2
15
Spacer Φ32x16
2
49
Handle cap
2
16
Spacer φ32xφ26.8xφ19x28
8
50
Handlebar cap
2
17
Flat washer φ21xφ27x0.3
2
51
Handlebar foam
2
18
Flat washer Φ10.5xφ32x2
2
52
Computer
1
19
Nut M10.5x1.25
2
53
Handlebar cover
1
20
Nut M8
10
54
Bolt M8x30
2
21
Washer D8
12
55
Steering wheel
1
22
Sleeve Φ10.1xφ14x10
4
56
Heart rate measurement cable
2
23
Bolt M8x45
4
57
Bolt M5x55
1
24
Bolt ST4.2x18
37
58
Curved washer d5
1
25L/R
Pedal base cover, left/right
2/2
59
Handlebar post
1
26
Bolt M8x75
2
60
Resistance adjustment knob
1
27L/R
Pedal base left/right
1/1
61
Flat washer d5
2
28
Bolt ST4x20
2
62
Bolt M5x10
2
29L/R
Left/right pedal
1/1
63A/B
Resistance adjustment knob cover
1/1
30
Bolt M8x74
2
64A/B
Handle arm cover
1/1
31
Front base pad
2
65
Water bottle
1
32
Sleeve φ32xφ26.8xφ14x28
4
66
Screw
2
33
Spacer Φ32x59
2
67
Flat washer
2
34L/R
Handlebar post cover, left/right
1/1
68
Water bottle holder
1
