Zipro Rook Gold - Parts Identification; Component List

25
EN
PARTS LIST
No.
Description
Quantity
No.
Description
Quantity
1
Main frame
1
24
Computer cable
1
2
Rear base
1
25
Handlebar post
1
3
Front base
1
26
Computer bolt
4
4
Base cap
4
27
Flat washer
3
5
Level foot
4
28
Locknut
3
6
Hexagonal nut
4
29
Handlebar adjustment knob
1
7
Hexagonal bolt
4
30
Computer
1
8
Curved washer
4
31
Flat washer
1
9
Hexagonal bolt nut
4
32 L/R
Handlebar cover, rear/front
1/1
10 L/R
Left/right pedal
1/1
33
Cross-head bolt
11
11 L/R
Left/right crank
1/1
34
Cross-head bolt
4
12
Saddle height knob
1
35
Steering wheel
1
13
Saddle post
1
36
Heart rate measurement cable
2
14
Saddle horizontal position knob
1
37
Handlebar foam
2
15
Saddle horizontal position knob
washer
1
38
Handlebar cap
2
16
U-bracket for horizontal saddle
positioning
1
39
Curved washer
2
17
Saddle guide cap
2
40
Flat washer
4
18
Saddle guide
1
41
AC adapter
1
19 L/R
Saddle guide cover, left/right
1/1
42
Flat washer
2
20
Saddle
1
43
Water bottle
1
21
Hexagonal bolt
2
44
Water bottle holder
1
22
Handlebar post cover
1
45
Screw
2
23
Connecting cable
1
