Updating firmware
NOT AVAILABLE
Update
in progress
This screen is displayed to alert the user that a firmware
update is in progress and that the Recharge Point is not
available at that time.
In this screen, neither the buttons nor the RFID are applied.
It returns to the default screen when the update is complete
and can return to normal operation.
LEDs Color
Blinking yellow.
Button Action
None.
RFID Action
None.
EV Action
- Open charging session:
o Changes to ‘A’ state Stopping Session.
o Changes to other states  None.
- Without charging session  None.
Applied change
Change
applied
This screen is displayed each time a configuration change
is made. This screen will last approximately 2-3 seconds.
Afterwards, you will move to the upper preview screen.
LEDs Color
Blinking white.
Button Action
ESC  Goes to the upper preview screen.
RFID Action
None.
EV Action
None.
Out of service
Out of service
This screen is displayed immediately in case of hardware
failure (from any screen) and is not exited from this screen
until the user fixes the cause of the failure.
LEDs Color
Red.
Button Action
None.
RFID Action
None.
EV Action
None.
Bluetooth: associate card
SWIPE CARD TO
ASSOCIATE
This screen will be displayed when the devices are linked
for the first time.
LEDs Color
White.
Button Action
ESC  Goes to Start screen.
RFID Action
Linking is performed:
- Failed linking  Goes to Error associating.
- Successful linking  Goes to Card associated.
EV Action
None.
