5.4.2 I/O Board
On the device module, click Device > I/O Board > New to add the I/O Board device to the software.
Enter the name of the I/O Board. Select the Device by clicking the Device Name field. The device list
appears, as shown below:
Select the device and click OK. Select the I/O Board Type. Set the RS485 Code Address by changing the
corresponding button. Click OK to save the details. You can view all the auxiliary inputs in the Auxiliary
Input interface.
Note: Please select this method when adding DM10 and AUX485.
