ZKTeco F18 Installation Guide

5
6
3.39in
(86mm)
3.0in
(76.1mm)
1.78in
(45.1mm)
8.07in
(205mm)
7.34in
(186.5mm)
Product Dimension Cables and Connectors
1
12
PIN DESCRIPTION WIRE
1 AL+
2 AL-
3 NC1
White
4 COM1
5 NO1
6 BUT Blue
7 GND
8 SEN Yellow
9 BELL+ Orange
10 BELL- Green
Digital input and Relay output
1
8
PIN DESCRIPTION WIRE
1
WD0 Green
2
WD1 White
3 GND Black
4
RXD Gray
5
6 GND Black
7
8
Wiegand output and RS485
1
7
PIN DESCRIPTION WIRE
1
+12V Red
2
GND Black
3
IWD1 Green
4
IWD0 White
5
6
7

Beep

LED

Wiegand Input

Power Out
Wiegand input and Power out
RJ 45
1
2
3
4
5
6
7
8
1
4
PIN DESCRIPTION WIRE
1 RJ45-6
Yellow
2 RJ45-3
Green
3 RJ45-2
4 RJ45-1

TCP/IP
Ethernet
1
2
PIN DESCRIPTION WIRE
1
+12V Red
2

Power In
Power
11
12

Alarm

Lock

Exit Button


Doorbell
Door Sensor

Auxiliary In
GND
Purble
Aux
Brown
Red
Black
Gray
Black
Red

RS485

RS232

Wiegand Out
485B Yellow
485A Blue
TXD Purple
BEEP
Brown
GLED Gray
RLED Blue
Black
Red
GND Black
2.4 Inch TFT Time Attendance &Access Control Terminal INSTALLATION GUIDE 2.4 Inch TFT Time Attendance & Access Control Terminal INSTALLATION GUIDE

ZKTeco F18 Specifications

General

Type	Basic access control reader
Product color	Gray
Number of users	1 user(s)
Access code reader	-
Fingerprint reader	Yes
Authentication type	Biometric
Display type	TFT-LCD
DC voltage range	0 - 12 V
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	183 mm
Width	80 mm
Height	42 mm
