4
RS485 and RS232 Connection
TXD
RXD
GND
RS232
Reader
Wiegand Input Connection
WD0
WD1
+12V
GND
Wiegand Reader
+12V
IDW1
IDW0
GND
485B
485A
GND
TXD1
RXD1
GND
TXD2
RXD2
485+
485-
GND
RXD
GND
TXD
RS232
Reader
RS485
Reader
