安装
步
骤
Installation
1. Drill holes on the door
d
esi
r
ed
ha
n
dl
e
h
e
i
gh
t
9
door thickness
35~65mm
center line of the
handle
backset 60mm
Note1:Align the template along the vertical center
line of the mortise(E)at the desired handle
height, and tape it to door.
Note2:Mark the holes first, then start drilling.
1.0m
0.5m
If the user height is 1.35-1.80m, the
height from handle centerline to
ground is 1m.
Recommended installation height
