A child or adult can tip the range and be killed; Re-engage the anti-tip device if the range
is moved. Failure to do so can result in death or serious burns to children or adults.
Installing the Anti-Tip Stability Device
WARNING!
1
2
3
4
5
e Anti-tip bracket shipped with the range must be properly
secured to the rear wall as shown in the picture below.
e height of the bracket from the oor must be determined aer the range legs
have been adjusted to the desired height and aer the range has been leveled.
7
Measure the
distance from the oor to the bottom of the Anti-Tip bracket
receptacle on the back of the appliance.
Position the two anti-tip brackets on the wall at the desired height plus 1/8 (0.32
cm). The brackets must be placed at 2 & 5/16" (6.0cm) from the side of the
range. The distance between the two brackets is 25 & 1/4 "(64.1 cm).
Secure the brackets to the wall with appropriate hardware.
Slide the range against the wall until the brackets are fully inserted into their recep-
tacles’ on the back of the range.
Check to see that the Anti-Tip device is installed properly. en grasp the top rear
edge of the range and carefully attempt to tilt it forward. Verify that the Anti-Tip
device is engaged.
Or use the anti-tip device as one chain, and tighten up with xed screw on the wall.
If the wall is not suitable for installation, then the chain shall be xed to the cabinet
stucture.
e two sides of the chains are xed on the wall or cabinet structure.
