BOAT ASSEMBLY
CHOOSE A SMOOTH, CLEAN SURFACE.
IF THE BUOYANCY TUBE WAS STORED AT A TEMPERATURE BELOW 0°C / 32°F,
LEAVE IT AT 20°C / 68°F FOR 12 HOURS BEFORE UNFOLDING.
INSTALLING THE REMOVABLE RECESSED STOWAGE BOX (INT’L SYSTEM ONLY).
CAUTION
THE STOWAGE BOX MUST BE INSTALLED ON ITS FLANGE BEFORE INFLATING THE
MAIN BUOYANCY TUBE.
IF THE TUBE IS INFLATED WITHOUT THE BOX, THE POCKET PROVIDING SEALING
INTEGRITY MAY BE DAMAGED.
TO LOCK THE BOX ON ITS FLANGE, INSERT THE BOX LUGS INTO THE
CORRESPONDING SOCKETS ON THE FLANGE.
CAUTION THERE IS A PREFERENTIAL POSITION (LOCK SLOT TOWARDS THE INSIDE
AND IN THE BOAT'S LONGITUDINAL CENTERLINE) TO ALLOW THE BOX TO BE
TURNED TO ITS LOCKED POSITION.
CAUTION:
THE BOAT MUST BE DEFLATED FOR THE
INSTALLATION
THE BOAT MUST NEVER BE INFLATED WITHOUT THE
BOX BEING INSTALLED.
1- Insert the box into the buoyancy tube flange.
The lock closing slot must be in the boat's longitudinal
centerline and towards the inside of the deck
2- Lock the box by turning it through a 1/6th of a turn
in the clockwise direction.
3- Make sure that the box is properly locked and fully
home.
You can then inflate the boat
4- Always use the key to open or close.
REMOVING THE REMOVABLE RECESSED STOWAGE BOX.
CAUTION
IT IS ESSENTIAL TO DEFLATE THE BOAT (ZERO PRESSURE) BEFORE REMOVING THE
REMOVABLE BOX.
TO FOLD THE BOAT AFTER DEFLATING IT, FIRST REMOVE THE REMOVABLE BOX
(following the assembly procedure in the reverse order).
