OPERATION OF THE PRESSURE REDUCER ADAPTER ZODIAC
ERB 310
NOTICE
Pressure reducer adaptor comprises: “A” Clamp, “A” clamp/DIN fitting
adaptor, one meter hose, plus C7 / IC valve adaptor.
Item 4
C7/IC Valve
Adaptor
Item
2
Adaptor ‘A’ Clamp
5/8
th
Din
Item 3
High Pressure Hose 1m
(Inc C/W end fitting)
Item 1
‘A’ clamp
