Connecting the “A” Clamp to the cylinder via an “A” clamp 5/8
th
din adaptor
Connect (item 1) “A” Clamp & (item 2) “A” clamp 5/8
th
din to the cylinder (item 5) as shown.
Make sure all components are clamped securely to prevent any loss of air during inflation.
Note: The above image is used to illustrate a bottle fitted with “A” Clamp connection (item 1) and “A”
clamp 5/8
th
Din Adaptor (item 2). If you have a bottle with the “A” clamp adaptor already fitted, same
processes minus item 2.
Item 5
Item 2
Item 1
