Figure 1. Connect the Power Cord
To Disconnect:
• Grip the power cord rmly on each side and
press two tabs to release (see Figure 2.)
Figure 2. Disconnect the Power Cord
2.4 Connecting to Power Source
WARNING
Failure to comply with the following warnings can
result in permanent injury, electrocution or drowning.
PREVENT ELECTRICAL SHOCK
• Keep the control unit at least five 3.5 m from the
edge of the pool.
• The cleaner is to be installed in accordance with the
relevant requirements of South African wiring rules,
or in Australia within requirements of wiring rules AS/
NZS 3000. Also refer to the installation instructions
relating to the swimming pool equipment for which
the cleaner will be an integral part. The cleaner is
to be supplied through a Residual Current Device
(RCD) with a rated residual operating current of
30mA.
• Do not use an extension cord to connect the control
unit.
• Do not allow anyone to swim while the cleaner is in
the pool.
• The control unit is water-resistant, not waterproof.
In order to prevent electrocution, never submerge
the control unit or leave exposed to inclement
weather.
To Connect:
• Rotate the power cord so that TOP is shown on
the top side. Press the power cord rmly into
the control unit until you hear a "click" (see
Figure 1). The clicking indicates the power cord
is connected correctly creating a watertight seal.
Page 5
