Zodiac vortex 2 - Immersing the Cleaner; Electrical Connection


H04268‐00.A3EN–2013‐09
 3

1.4Packagecontent

‐ thecleaner
‐ acontrolbox
‐ afloatingcable
‐ ausermanual
‐ thewarranteebooklet

1.5Immersingthecleaner


 Placethecleanerverticallyintothewater(1)andmoveitslightlyinalldirectionssothattheaircontainedinthe 
cleanerescapes(2).
 Itisessentialthatthecleanersinksonitsownandsettlesonthepoolbottom.Spreadouttherequiredlengthof
cablebythepool.Foroptimumoperationwerecommendthatyo
uplacethecaddywiththecontrolboxatthe
centreofthepoollength(3).









1.6Electricalconnection



 Unscrewtheprotectivecap.

 Connectthefloatingcabletothecontrolbox(1)andlockit
intoplace:firmlytightentheringbyturningitclockwise(2).
Make sure the connector issufficiently pushed into place. If
thisisnotthecaserepeattheoperation.

 Connectthemainscable.Onlycon nectthecon trolboxtoa
power outlet  protected by a 30 mA maximum ground fault
circuitbreaker(ifindoubtcontactaqualifiedelectrician).










Donotuseyourcleanerduringshockchlorination!

Donotallowbathingwhenthecleanerisinthepool.

Placethe controlboxatadistance ofat least 3.5 metresfromthe edge ofthepool avoidingplacing
thecontrol boxin direct sunlight.Prefer a location thatis clean  anddry,flat andfree of anyobject
thatcoulddamagetheunderpartofthecontrolbox.

Don’tforgettoscrewtheprotectivecapbackonifyouunplugthecontrolboxpowercord.




