4.2Replacingthebrushes

 ThecleanerisfittedwithPVCbrushes.Theyhavewearindicators(1).
 Toremovewornbrushes,removethetabsfromtheholesinwhichtheyarefixed.
 Tofitnewbrushesstartbyfittingthesidewithouttabsunderthebrushholder(2).
 Rollthebrusharounditss
upportandslidethetabsintothefixingholes(3).
 Pullontheendofeachtab(4)untilitsedgepassesthroughtheslit.
 Cutthetabsusingscissorssothattheyareatthesamelevelastheotherblades(5).







4.3Changingthebands







4.4.Maintenanceofyourcleaner


 The cleaner must be cleaned regularly using clean or slightly soapy water, do not use solvents such as
trichloroethyleneoritsequivalent.Rinsethecleanergenerouslyusingcleanwater.Donotletyourcleanerdryin
thesunbythepool.
 Rollupthecablewithcautionwhenstoringitsoastoavoidtanglin
g.

4.5Recycling

This symbol on a new appliance means that the equipment must not be thrown away, it will be
selectivelycollectedfor thepurposeofreuse,recyclingorcreatingvalue.Ifitcontainssubstances  that
are potentially harmful to the environment, they will be eliminated or neutralised. Ask your reseller
abouthowtorecy
cleyourapplianceandthebodies thatcandoso.

5.Troubleshooting

5.1MeaningofControlindicatorLedBLINKS

 Ifthe Ledisoff,thecleanerisoperatingnormally.Itisnotcommunicatinganyinformation.
 Ifthe
Ledisblinking,thecleanerissignallingthatyoushouldperformcheckstoimprovecleaning.

Iftheproblemcontinuescontactyourreseller.

Werecommendthatyoureplacethebrusheseverytwoseasons.
Problems Solutions

 Checkthat thecleaneris correctly connected tothecontrolbox. If
necessary, unplug it and  reconnect it following the appropriate
procedure.

 Checkthatnothingisstop pingthebrushesfromturningcorrectly
(sand,cable,etc.).Todothisturnthewheeltotheleftandthen
rightone1/4turninbothdirections.

 Robotoperatingoutsidethepool.
Makesureyoustartthecleanerwhenitisinthewater(see§1.5).
 Checkforthepresenceofpebblesorhairinthefan,cleanthefilter.









