Zodiac Vortex 3 4WD - FLASHING LIGHTS AFTER START-UP (< 20 SECONDS); FLASHING LIGHTS DURING CYCLE; TECHNICAL INFORMATION

H0360600.A2.EN Ver.05/2011 10
Issue:Theflashinglightsappearsjustafterstartingthecleaner(<20seconds).

Solution:
x Ensurethefloatingcableisconnectedtothecontrolunit.
x Disconnectthefloatingcablefromthecontrolunitandconnectitagainproperly.
x Ensurethecleaneriswellsubmerged.
x Then start a new cycle and check that the impeller is rotating correctly (water ejected at the rear of the
robot)andthatthewheelsarerotating(twowheels=Vortex™3andVortex™4;4wheels=Vortex™34WD).
x Iftheimpellerdoesn'tturn,checkifthereissomedebrisaroundtheimpeller.

Procedure:
x Ensurethatthecontrolunitcablehasbeendisconnectedfromtheelectricaloutletorthatthefloatingcable
hasbeendisconnectedfromthecontrolunit.
x Liftthecover.Removethefilterbasket.

x Loosenthescrewsholdingthecovergridinplace.(Diagram211).
x Pushtheedgesofthecovergridtogether(212)atthesametimeliftingit(213).
x Lifttheendoftheflowoutlet(214)andthesametimepullitout(215).
x Cleantheimpellerortheflowoutletandreassemblyallthepartsproperly.
x Checkthecleaneragaininthepool:iftheimpellerdoesn't'rotatepleasecontactyourretailer.
Ifoneofthewheelsisblocked,pleasecontactyourretailer.

Issue:Theflashinglightsappearduringthecycle.
x Ifthecleanersucksairfor60seconds,theflashinglightappears.
Solution:
x Submergedthecleanerinthepoolagain.

TECHNICALINFORMATION

Controlboxsupplyvoltage:220240VAC;50Hz Weightofrobot:9,5kg
Robotsupplyvoltage:30VDC Packedweight:19kg
Installedload:150Wmax Widthcleaned:270mm
Cablelength:18mor21m(Vortex™4) Pumpoutput:16m3/h
Robotsize(WxDxH):43x48x27cm Cyclelengths:1h30and2h30
Packsize(WxDxH):56x56x56cm

WARRANTIES

Principle
Unless otherwise stipulated, we contractually guarantee the correct operation of our new Products. We
guarantee that our Products conform to their technical specifications and that they are free of material and
manufacturingdefault.
The present warranty is limited, at our discretion, either to the repair or exchange for a new or repacked
Product,ortotherefundofanyProductsrecognizedasbeingdefectivebyourservices.Shippingexpensesfor
therepairedorreplacedProductsdeliveredtotheclientwillbebornebyus.Theguaranteeexcludesanylabour
costs, travel and/or accommodation expenses incurred as the result of repairs made outside of continental
Franceandexcludesanypaymentofdamages.
AllProductreturnsmustfirstbeapprovedanddeterminedbyourservices.ReturnssentbytheClientwithout
ourpriorapprovalwillnotbeaccepted.
Diagram21
EN
