Zodiac VORTEX-PRO VX50 4WD - Replacing the Brushes

After every cleaning cycle:
1. Unplugtheoatingcableatthecontrolbox.
2. Remove the cleaner from the pool and untangle
anykinksandcoilsintheoatingcablestarting
at the cleaner head.
3. Removeltercanisterandrinsewithclean
water.Plugtheoatingcablebackintothe
control box and store cleaner for next use.
6.3 Replacing the Brushes
ThecleaneristtedwithPVCbrushes.Thereare
''wear'' indicators on the brushes (Figure 32). To
maintain cleaner performance at its best you need
to replace the brushes as soon as one of the wear
indicators is reached (even if the blade wear is not
even). It is recommended that you replace the brushes
when the rubber is worn down to the top of the wear
indicator(oreverytwoyears,whichevercomesrst).
Figure 32. Wear Indicators
1. Lift the cleaner to a vertical position so that the
handle is up (Figure 33).
1
Figure 33. Cleaner in Upright Position
2. Separate the edges of the brush and undo the
tabs (Figure 34). Remove the worn brushes.
2
Figure 34. Undo the Tabs of the Brush
H0516700_REV C
18
