FIGURE 1
ASSEMBLY WITH COLUMN PUMP
FIGURE 2
ASSEMBLY WITH SUBMERSIBLE PUMP
NOTE: Pump must be mounted on a 30º angle to avoid airlocking NOTE: Pump must be mounted on a 30º angle to avoid airlocking
OUTLET
PUMP
PRIMARY
1" MIN.
IMPORTANT: OFF LEVEL
OF FLOAT ASSEMBLY
MUST BE HIGHER THAN
DC BACKUP PUMP
DC PUMP PLUMBED IN LINE WITH SUBMERSIBLE PUMP
BATTERY BOX
TM
R
TM
R
BATTERY BOX
OUTLET PRIMARY PUMP
DC PUMP PLUMBED IN LINE WITH COLUMN PUMP
IMPORTANT: OFF LEVEL
OF FLOAT ASSEMBLY
MUST BE HIGHER THAN DC BACKUP PUMP
1" MIN.
SK2499
SK2500
NOTE: The section of pipe below the tee determines the height of the DC pump. A shorter piece of pipe may be benecial in some installations. This drawing is dimensioned for clarity.
NOTE: The section of pipe below the tee determines the height of the DC pump. A shorter piece of pipe may be benecial in some installations. This drawing is dimensioned for clarity.
