3
The DC controller is equipped with a 10 amp charger for main tain ing the battery in a ready state and re charg ing the battery after use when
AC power is restored. Time for recharge depends upon the amount of power consumed by the pumping cycle during the AC power inter-
rup tion. The pump may go back to the ready run position in a very short period of time. A com pletely drained battery may require up to 24
hours for full recharge. If after 24 hours of charging the battery has not reached 6 volts, the alarm will sound and not reset until the battery
is brought up to a voltage of 6.5-7.0 volts.
© Copyright 2009 Zoeller Co. All rights reserved.
MODELS: 507-C 507-D
ITEM DESCRIPTION QTY
4/96
thru
10/05
11/05
thru
Current
1 DC backup pump 1 010475 017198
2 Plastic battery box with safety closure strap 1 005702 005702
3 DC control charger with terminals 1 011323 011323
4 “Off”/”On” fl oat switch 1 017197 017197
5 1½" x 5" long PVC pipe nipple 1 005639 N/A
6 Check valve (2) REV C - (1) REV D 005636 005636
7 Reducer hose coupling and clamp 1 30-0188 N/A
8 1¼" x 1" PVC reducer fi tting 1 005642 N/A
9 1" pipe to hose adapter elbow 1 005643 N/A
10 1" hose coupling and two clamps 1 005703 N/A
11 1½" PVC pipe tee 1 005645 005645
12 1½" 90 degree PVC pipe elbow 1 005644 N/A
13 1¼" x 1¼" PVC coupling 1 009129 N/A
14
Pump mounting kit, includes brkt, S.S. worm drive clamp, two #10-24 screws
and washers.
1 005704 N/A
15 Cable tie 1 005868 N/A
16 Anchors, wall 2 009691 009691
17 Bracket, control mounting 1 007779 007779
18 1½" x 1½" PVC coupling 1 N/A 009746
Checklist
Performance
The DC emergency pump system requires a good quality, 12 volt battery to obtain maximum pumping time during a power outage. A deep-
cycle, 12 volt, 105 amp-hour marine battery or larger is rec om mended and will provide approximately 7½ hours of continuous pumping
time in a sump pump installation with 8' of head pressure. In most installations the pump runs intermittently and the battery life is extended
accordingly. Batteries with top terminals are recommended for ease of installation. These batteries contain acid and proper precaution must
be taken when handling. Maximum battery size 12½" Length x 7" Width x 9½" Height.
Battery Selection
Discharge
Feet of Head
5 10 15 17.5
Flow
Gal. per min.
23 15 5
Shut-off
Head
The DC pump performance with fully charged 12V battery
The DC emergency pump is designed as a backup to your primary sump pump during unexpected power out ages or primary pump failure.
The DC pump, elec tronic controls and all the parts required for in stal la tion are included except the battery which is supplied by the user.
The system is de signed for installation in sumps with minimum of 18" di ame ter and 24" deep. For 18" x 22" applications, consult factory.
Description
Troubleshooting Information, continued
7. Water level stays high. DC Pump continues to run.
(a) Battery is low.
(b) If power has been restored and water in sump re mains high
check primary pump. Service if re quired.
(c) After several hours the battery will be restored to full charge.
8. Alarm sounds during battery recharge cycle.
(a) Push alarm reset (max. 3 times). If condition persists,
replace battery.
(b) To silence alarm if alarm will not reset, unplug the charger
from 115V wall outlet, then disconnect the black lead from
charger on negative (-) battery post. Check battery. Replace
if necessary. Reconnect and refer to Installation (step 14).
