ELECTRICAL DATA, continued
* Line to line reading will only reect the run winding resistance.
** Line to line reading will only reect the relay coil resistance on automatic 160-290 series.
Start winding resistance can only be measured after removing the cover.
Note: For total resistance including power cable, see chart on page 5.
MX282 1/2 1750 115 1 60 10.3 7.3 30.2 H 1.4/1.2*
NX282 1/2 1750 115 1 60 10.3 7.3 30.2 H 1.4/1.2*
DX282 1/2 1750 230 1 60 5.0 4.0 15.1 H 5.7/4.9*
EX282 1/2 1750 230 1 60 5.0 4.0 15.1 H 5.7/4.9*
HX282 1/2 1750 200 1 60 6.1 4.5 17.7 H 4.7/4.0*
IX282 1/2 1750 200 1 60 6.1 4.5 17.7 H 4.7/4.0*
JX282 1/2 1750 200 3 60 3.6 2.5 12.8 K 7.9/6.9
FX282 1/2 1750 230 3 60 3.0 2.3 12.2 L 9.4/8.1
GX282 1/2 1750 460 3 60 1.7 1.1 6.1 L 37.4/32.5
BAX282 1/2 1750 575 3 60 1.4 1.1 5.11 M 63.6/55.3
DX284 1 1750 230 1 60 8.9 6.7 24.9 G **
EX284 1 1750 230 1 60 8.9 6.7 24.9 G 2.5/2.2*
HX284 1 1750 200 1 60 9.3 6.4 26.8 F **
IX284 1 1750 200 1 60 9.3 6.4 26.8 F 2.0/1.8*
JX284 1 1750 200 3 60 5.5 4.0 26.3 L 3.0/2.6
FX284 1 1750 230 3 60 5.0 4.0 22.2 K 4.9/4.3
GX284 1 1750 460 3 60 2.6 1.9 11.1 K 19.0/17.0
BAX284 1 1750 575 3 60 2.2 1.7 12.1 N 20.4/17.7
MX292 1/2 3450 115 1 60 15.0 10.6 52.2 N **
NX292 1/2 3450 115 1 60 15.0 10.6 52.2 N .53/.46*
DX292 1/2 3450 230 1 60 7.5 4.7 15.1 H 4.6/4.0*
EX292 1/2 3450 230 1 60 7.5 4.7 15.1 H 4.6/4.0*
HX292 1/2 3450 200 1 60 8.8 7.4 19.8 J 3.5/3.0*
IX292 1/2 3450 200 1 60 8.8 7.4 19.8 J 3.5/3.0*
JX292 1/2 3450 200 3 60 6.4 4.0 23.6 S 6.1/5.3
FX292 1/2 3450 230 3 60 5.2 3.5 24.0 T 5.5/4.8
GX292 1/2 3450 460 3 60 2.9 1.7 12.0 T 22.1/19.2
BAX292 1/2 3450 575 3 60 2.4 1.7 11.3 U 38.0/33.0
DX293 1 3450 230 1 60 10.2 6.6 20.1 E **
EX293 1 3450 230 1 60 10.2 6.6 20.1 E 3.0/2.6*
HX293 1 3450 200 1 60 12.0 7.5 26.8 F **
IX293 1 3450 200 1 60 12.0 7.5 26.8 F 2.0/1.8*
JX293 1 3450 200 3 60 8.2 5.2 31.1 M 3.6/3.2
FX293 1 3450 230 3 60 7.6 5.2 29.8 N 5.5/4.7
GX293 1 3450 460 3 60 4.0 2.6 14.9 N 21.8/19.0
BAX293 1 3450 575 3 60 3.3 2.1 10.0 L 39.2/34.1
DX294 1-1/2 3450 230
1 60 13.7 9.7 45.7 H **
EX294 1-1/2 3450 230 1 60 13.7 9.7 45.7 H 1.3/1.1*
HX294 1-1/2 3450 200 1 60 17.8 11.6 54.5 J **
IX294 1-1/2 3450 200 1 60 17.8 11.6 54.5 J .84/.73*
JX294 1-1/2 3450 200 3 60 10.8 6.2 45.2 M 2.5/2.2
FX294 1-1/2 3450 230 3 60 9.5 5.6 39.4 M 3.4/2.9
GX294 1-1/2 3450 460 3 60 4.8 2.8 19.7 M 13.5/11.7
BAX294 1-1/2 3450 575 3 60 3.8 2.2 15.9 M 20.8/18.1
DX295 2 3450 230 1 60 17.1 12.0 45.7 F **
EX295 2 3450 230 1 60 17.1 12.0 45.7 F 1.3/1.1*
HX295 2 3450 200 1 60 20.5 14.7 54.5 F **
IX295 2 3450 200 1 60 20.5 14.7 54.5 F .84/.73*
JX295 2 3450 200 3 60 14.3 8.8 45.2 J 2.5/2.2
FX295 2 3450 230 3 60 12.2 7.5 39.4 J 3.4/2.9
GX295 2 3450 460 3 60 6.1 3.8 19.7 J 13.5/11.7
BAX295 2 3450 575 3 60 4.9 3.0 15.9 J 20.8/18.1
EX404 2 1750 230 1 60 12.9 9.9 44.8 B 1.80/1.60*
IX404 2 1750 200 1 60 14.4 11.5 49.6 B 1.4/1.3*
JX404 2 1750 200 3 60 13.8 13.1 56.8 H 1.6/1.3
FX404 2 1750 230 3 60 10.5 9.7 44.6 G 2.3/2.0
GX404 2 1750 460 3 60 5.2 4.8 22.3 G 9.1/8.0
BAX404 2 1750 575 3 60 4.1 3.8 17.6 G 14.6/12.7
EX405 3 1750 230 1 60 19.0 9.3 44.8 B 1.80/1.60
IX405 3 1750 200 1 60 20.2 8.8 49.6 B 1.4/1.3*
JX405 3 1750 200 3 60 14.8 12.5 56.8 H 1.6/1.3
FX405 3 1750 230 3 60 12.2 9.7 44.6 G 2.3/2.0
GX405 3 1750 460 3 60 6.1 4.8 22.3 G 9.1/8.0
BAX405 3 1750 575 3 60 4.8 3.8 17.6 G 14.6/12.7
Model HP RPM Voltage Phase Hertz
Amps
Winding
Resistance
Line-to-Line
Full Load Shut Off
Locked
Rotor
"KVA
Code"
