ELECTRICAL DATA
* Line to line reading will only reect the run winding resistance.
** Line to line reading will only reect the relay coil resistance on automatic 160-290 series.
Start winding resistance can only be measured after removing the cover.
Note: For total resistance including power cable, see chart on page 5.
CONTINUED ON NEXT PAGE
Model HP RPM Voltage Phase Hertz
Amps
"KVA
Code"
Winding
Resistance
Line-to-Line
Full Load Shut Off
Locked
Rotor
MX161 1/2 3450 115 1 60 15.0 7.7 52.2 N **
NX161 1/2 3450 115 1 60 15.0 7.7 52.2 N .53/.46*
DX161 1/2 3450 230 1 60 7.5 3.6 15.1 H **
EX161 1/2 3450 230 1 60 7.5 3.6 15.1 H 4.6/4.0*
HX161 1/2 3450 200 1 60 8.8 6.3 19.8 J **
IX161 1/2 3450 200 1 60 8.8 6.3 19.8 J 3.5/3.0*
JX161 1/2 3450 200 3 60 6.4 3.1 23.6 S 6.1/5.3
FX161 1/2 3450 230 3 60 5.2 2.7 24.0 T 5.5/4.8
GX161 1/2 3450 460 3 60 2.9 1.4 12.0 T 22.1/19.2
BAX161 1/2 3450 575 3 60 2.4 1.3 11.3 U 38.0/33.0
MX163 1/2 3450 115 1 60 15.0 8.4 52.2 N **
NX163 1/2 3450 115 1 60 15.0 8.4 52.2 N .53/.46*
DX163 1/2 3450 230 1 60 7.5 4.0 15.1 H **
EX163 1/2 3450 230 1 60 7.5 4.0 15.1 H 4.6/4.0*
HX163 1/2 3450 200 1 60 8.5 4.3 19.8 J **
IX163 1/2 3450 200 1 60 8.5 4.3 19.8 J 3.5/3.0*
JX163 1/2 3450 200 3 60 6.0 3.4 23.6 S 6.1/5.3
FX163 1/2 3450 230 3 60 4.8 3.0 24.0 T 5.5/4.8
GX163 1/2 3450 460 3 60 2.9 1.5 12.0 T 22.1/18.2
BAX163 1/2 3450 575 3 60 2.4 1.5 11.3 U 38.0/33.0
DX165 1 3450 230 1 60 10.2 5.5 20.1 E **
EX165 1 3450 230 1 60 10.2 5.5 20.1 E 3.0/2.6*
HX165 1 3450 200 1 60 12.6 6.1 26.8 F **
IX165 1 3450 200 1 60 12.6 6.1 26.8 F 2.0/1.8*
JX165 1 3450 200 3 60 7.5 4.8 31.1 M 3.6/3.2
FX165 1 3450 230 3 60 7.4 3.8 29.8 N 5.5/4.7
GX165 1 3450 460 3 60 3.7 2.1 14.9 N 21.8/19.0
BAX165 1 3450 575 3 60 3.0 1.7 10.0 L 38.8/34.5
DX185 1 3450 230 1 60 9.8 5.0 20.1 E **
EX185 1 3450 230 1 60 9.8 5.0 20.1 E 3.0/2.6*
HX185 1 3450 200 1 60 11.5 5.1 26.8 F **
IX185 1 3450 200 1 60 11.5 5.1 26.8 F 2.0/1.8*
JX185 1 3450 200 3 60 7.5 3.6 31.1 M 3.6/3.2
FX185 1 3450 230 3 60 7.4 3.8 29.8 N 5.5/4.7
GX185 1 3450 460 3 60 3.7
1.9 14.9 N 21.8/19.0
BAX185 1 3450 575 3 60 3.3 1.6 10.0 L 38.8/34.5
DX186 1-1/2 3450 230 1 60 13.7 9.3 45.7 H **
EX186 1-1/2 3450 230 1 60 13.7 9.3 45.7 H 1.3/1.1*
HX186 1-1/2 3450 200 1 60 17.2 11.8 54.5 J **
IX186 1-1/2 3450 200 1 60 17.2 11.8 54.5 J .84/.73*
JX186 1-1/2 3450 200 3 60 10.3 6.0 45.2 M 2.5/2.2
FX186 1-1/2 3450 230 3 60 9.2 5.5 39.4 M 3.4/2.9
GX186 1-1/2 3450 460 3 60 4.6 2.8 19.7 M 13.5/11.7
DX188 1-1/2 3450 230 1 60 14.0 7.4 45.7 H **
EX188 1-1/2 3450 230 1 60 14.0 7.4 45.7 H 1.3/1.1*
HX188 1-1/2 3450 200 1 60 16.8 9.8 54.5 J **
IX188 1-1/2 3450 200 1 60 16.8 9.8 54.5 J .84/.73*
JX188 1-1/2 3450 200 3 60 10.3 4.7 45.2 M 2.5/2.2
FX188 1-1/2 3450 230 3 60 8.9 4.1 39.4 M 3.4/2.9
GX188 1-1/2 3450 460 3 60 4.6 2.0 19.7 M 13.5/11.7
BAX188 1-1/2 3450 575 3 60 3.5 1.6 15.9 M 20.8/18.1
DX189 2 3450 230 1 60 17.1 9.4 45.7 F **
EX189 2 3450 230 1 60 17.1 9.4 45.7 F 1.3/1.1*
HX189 2 3450 200 1 60 20.5 11.5 54.5 F **
IX189 2 3450 200 1 60 20.5 11.5 54.5 F .84/.73*
JX189 2 3450 200 3 60 13.2 6.8 45.2 J 2.5/2.2
FX189 2 3450 230 3 60 11.2 5.1 39.4 J 3.4/2.9
GX189 2 3450 460 3 60 6.0 2.8 19.7 J 13.5/11.7
BAX189 2 3450 575 3 60 5.8 2.1 15.9 J 20.8/18.1
DX191 2 3450 230 1 60 14.5 8.5 45.7 F **
EX191 2 3450 230 1 60 14.5 8.5 45.7 F 1.3/1.1*
