Zoeller MX161 - Pump Dimensions

7
© Copyright 2020 Zoeller
®
Co. All rights reserved.
PUMP DIMENSIONS
6-1/2
[165mm]
8-3/4
[222mm]
1-1/2" NPT STANDARD
2" NPT
OR
3" NPT
AVAILABLE
22-29/32
[582mm]
4-9/16 [116mm]
4-9/16 [116mm]
23-9/32
[591mm]
1-1/2" NPT
CONDUIT CONNECTION
CHECK VALVE
6-1/16 [154mm]
OFF LEVEL MUST BE
SET AT A MIN. OF 10"
SK1912
X160 - X190 Series
6-5/16
[160mm]
8-9/16
[217mm]
5
[127mm]
5 [127mm]
23-5/32
[588mm]
2" NPT
OR
3" NPT
AVAILABLE
23-17/32
[598mm]
CHECK VALVE
1-1/2"NPT
CONDUIT CONNECTION
6-5/16 [160mm]
OFF LEVEL MUST BE
SET AT A MIN. OF 10"
SK1913
4-9/16”
8-3/4”
6-1/2”
1-1/2” NPT STANDARD
2” NPT
OR
3” NPT
FLANGE AVAILABLE
8-9/16” (217 mm)
1-1/2” NPT
CONDUIT
CONNECTION
24-15/16”
21-1/2”
4-29/32” (125 mm)
6-1/16” (154 mm)
(116 mm)
(222 mm)
(165 mm)
(633 mm)
(546 mm)
4-9/16” (116 mm)
SK2506
5”
(127 mm)
8-9/16”
(217 mm)
6-5/16”
(160 mm)
2” NPT
OR
3” NPT
FLANGE AVAILABLE
5” (127 mm)
8-9/16” (217 mm)
1-1/2” NPT
CONDUIT
CONNECTION
25-3/16”
(640 mm)
21-3/4”
(552 mm)
6-5/16” (160 mm)
SK2507
X280 Series
SK1914
6-1/2
[165mm]
8-3/4
[222mm]
1-1/2" NPT STANDARD
2" NPT
OR
3" NPT
AVAILABLE
22-29/32
[582mm]
4-9/16 [116mm]
4-9/16 [116mm]
23-9/32
[591mm]
1-1/2" NPT
CONDUIT CONNECTION
CHECK VALVE
6-1/16 [154mm]
OFF LEVEL MUST BE
SET AT A MIN. OF 10"
8-3/4
6-1/2
2" NPT
OR
3" NPT
FLANGE AVAILABLE
1-1/2" NPT
CONDUIT CONNECTION
6-1/16
21-1/2
24-15/16
4-9/16
8-9/16
4-9/16
SK2508
X290 Series
AUTOMATIC
AUTOMATIC
NONAUTOMATIC
NONAUTOMATIC
AUTOMATIC
NONAUTOMATIC
