Connection Examples
Connection with only one amplifier (Connection example 1)
To use the 9000 with only one guitar amplifier, connect the output from the musical
instrument to the IN/POWER connector of the 9000, and the OUT L connector of the
9000 to the amplifier. With this connection, stereo effects such as reverb, stereo chorus,
etc. are output as monaural.
Connection Example 1
Connection with two guitar amplifiers (Connection Example 2)
To use the 9000 with two guitar amplifiers, connect the OUT L/R connectors of the 9000
to the amplifiers. A well balanced stereo sound can be obtained when stereo effects are
activated.
Connection Example 2
OUT L
IN/POWER
OUT R
