Bank 1 / Patch 3 - NAME : Squeeze
COMP+DIST EQUALIZER MODULATION DELAY REVERB PATCH LVL
CLEAN TYPE TYPE TYPE 28
RHYTHM Eq MidEq Reverb 1
CRUNCH par1 Lo par1 Depth DECAY par1 Time
OVERDRV -4 10 3 7
þ DISTORTION par2 Hi par2 Freq TIME par2 Mix
COMP / 1 +5 5 35 2
par3 Paek MIX
4 4
Bank 1 / Patch 4 - NAME : Cry-Wah
COMP+DIST EQUALIZER MODULATION DELAY REVERB PATCH LVL
CLEAN TYPE TYPE TYPE 12
RHYTHM Eqce Cry Reverb 1
þ CRUNCH par1 Lo par1 Sense DECAY par1 Time
OVERDRV -2 5 10 0
DISTORTION par2 Hi par2 Dir TIME par2 Mix
COMP / 1 +3 0 8 3
MIX
8
Bank 2 / Patch 1 - NAME : Modern Jazz
COMP+DIST EQUALIZER MODULATION DELAY REVERB PATCH LVL
þ CLEAN TYPE TYPE TYPE 54
RHYTHM Eq Flange Reverb 1
CRUNCH par1 Lo par1 Depth par1 Time
OVERDRV -2 10 4
DISTORTION par2 Hi par2 Rate par2 Mix
COMP / 2 +5 0 4
par3 Peak
4
Bank 2 / Patch 2 - NAME : Echo Lead
COMP+DIST EQUALIZER MODULATION DELAY REVERB PATCH LVL
CLEAN TYPE TYPE TYPE 14
RHYTHM Enhance Flange Delay 2
CRUNCH par1 Depth par1 Depth DECAY par1 Decay
OVERDRV 9 7 2 7
þ DISTORTION par2 Freq par2 Rate TIME par2 Time
COMP / 0 8 6 40 6
pr3 Peak MIX par3 Mix
2 3 10
Bank 2 / Patch 3 - NAME : Chorus Lead
COMP+DIST EQUALIZER MODULATION DELAY REVERB PATCH LVL
CLEAN TYPE TYPE TYPE 24
RHYTHM Eq Chorus 1 Reverb 1
CRUNCH par1 Lo par1 Depth DECAY par1 Time
þ OVERDRV +2 7 6 7
DISTORTION par2 Hi par2 Rate TIME par2 Mix
COMP / 2 +3 4 26 2
par3 Mix MIX
6 3
Bank 2 / Patch 4 - NAME : Pitch Lead
COMP+DIST EQUALIZER MODULATION DELAY REVERB PATCH LVL
CLEAN TYPE TYPE TYPE 22
RHYTHM Enhance Pitch Reverb 1
CRUNCH par1 Depth par1 Pit DECAY par1 Time
þ OVERDRV 9 -5 4 4
DISTORTION par2 Freq par2 Fin TIME par2 Mix
COMP / 1 9 0 48 4
par3 Bal MIX
4 2
