11
Playing recordings
1

1.
Tap on the Home Screen.

Operations during playback
Function Operation
Pause/resume Tap
.
Search forward Hold
.
Search backward Hold
.
Move to the next mark (if one exists)
Play the next le (if no mark exists)
Tap
.
Move to the previous mark (if one exists)
Move to the beginning of the le (if no mark exists)
Tap
.
Play the previous le Tap
twice in a row.
Add a mark Tap
.
Stop Tap
.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zoom F2 and is the answer not in the manual?

Zoom F2 Specifications

LMF-2

Audio Specifications IconAudio Specifications
directionalityOmnidirectional
sensitivity–32 dB/Pa at 1 kHz
maximum sound pressure input115 dB SPL
Physical Characteristics IconPhysical Characteristics
cable length160 cm

F2/F2-BT

Audio Inputs and Outputs IconAudio Inputs and Outputs
input impedance2 kΩ or more
maximum input level-5.5 dBu
maximum output level20 mW + 20 mW (into 32Ω load)
Power IconPower
supported plug-in power2.5 V
power source2 AAA batteries (alkaline, lithium or rechargeable NiMH batteries)
AC adapterDC 5 V/1 A
Battery Life IconBattery Life
continuous recording time with alkaline batteriesabout 15 hours (F2) / about 14 hours (F2-BT)
continuous recording time with NiMH batteries (750 mAh)about 11 hours (F2) / about 10 hours (F2-BT)
continuous recording time with lithium batteriesabout 21 hours (F2) / about 18 hours (F2-BT)
Dimensions and Weight IconDimensions and Weight
external dimensions57.5 mm (W) × 46.4 mm (D) × 22.4 mm (H)
weight32 g
