5
Recording
Home/Recording Screen
Status icon
Elapsed recording time Battery Type
Remaining battery charge
Remaining recordable time
REC button
Screen operation lock switch
File name
Recording format
Lo cut setting
File note
Level meter
Output volume
REW button
STOP button
MENU button
FF button
MARK button
PLAY/PAUSE button
Screen operation lock switch settings
Setting Description
All screen operations are enabled.
All operations are disabled except the screen operation lock switch.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zoom F2 and is the answer not in the manual?

Zoom F2 Specifications

LMF-2

Audio Specifications IconAudio Specifications
directionalityOmnidirectional
sensitivity–32 dB/Pa at 1 kHz
maximum sound pressure input115 dB SPL
Physical Characteristics IconPhysical Characteristics
cable length160 cm

F2/F2-BT

Audio Inputs and Outputs IconAudio Inputs and Outputs
input impedance2 kΩ or more
maximum input level-5.5 dBu
maximum output level20 mW + 20 mW (into 32Ω load)
Power IconPower
supported plug-in power2.5 V
power source2 AAA batteries (alkaline, lithium or rechargeable NiMH batteries)
AC adapterDC 5 V/1 A
Battery Life IconBattery Life
continuous recording time with alkaline batteriesabout 15 hours (F2) / about 14 hours (F2-BT)
continuous recording time with NiMH batteries (750 mAh)about 11 hours (F2) / about 10 hours (F2-BT)
continuous recording time with lithium batteriesabout 21 hours (F2) / about 18 hours (F2-BT)
Dimensions and Weight IconDimensions and Weight
external dimensions57.5 mm (W) × 46.4 mm (D) × 22.4 mm (H)
weight32 g
