Functions added in Version 3.0
Monitoring the input signals of specific tracks (PFL/SOLO)
03
F
Multi Track Field Recorder
Monitoring the input signals of specific tracks (PFL/SOLO)
1. Press
l
on the tracks that you want to monitor.
The selected track keys will light orange, and the PFL screen
will open.
"PFL" or "SOLO" appears at the top of the display, and you
will be able to monitor the input signal with headphones.
PFL mode
Track name
Level meter
(prefader input
signal level)
Parameter names
Parameter Explanation
Source
This sets the input source. (→ P4 )
Trim This sets the input level.
Fader This sets the fader level.
Pan This sets the panning.
Phantom This sets phantom power.
Parameter Explanation
HPF This sets the high pass filter.
Input Limiter This sets the limiter.
Phase Invert This sets the phase.
Input Delay This sets the input delay.
Stereo Link This sets the stereo link.
PFL Mode This sets the monitoring volume on the PFL screen.
NOTE
This does not change the signals output from MAIN OUT and SUB
OUT.
HINT
Use
E to select parameters and change setting values.
2. Press
l
or m for the monitored tracks.
Open the Home Screen.
In Version 3.0, setting the input source was added. You can monitor the input signals of specified tracks. Even tracks that have
not been set to record can be input to the PFL screen and their input sounds monitored. This is convenient when using tracks as
return inputs. You can also make various settings for these tracks.
Functions added in Version 3.0
