RT55 Rough Terrain Crane 01 - 1
1.1 HOIST TACKLE CHART
This chart only represents the maximum permissible hoist line load per parts of line. You must
refer to the proper Lift Charts for machine rated loads.
Table 01 – 1 Line Parts
MAXIMUM PERMISSIBLE HOIST LINE LOAD
LINE PARTS
1 2 3 4 5 6 7 8 9 10
PERMISSIBLE
HOIST LINE
5500 11000 16500 22000 27500 33000 38500 44000 49500 55000
MAXIMUM
PERMISSIBLE
HOIST LINE
12125 24250 36375 48500 60625 72750 84875 97000 109125 121250
Wire rope: 19NAT-15×K7-IWRC-1960Mpa（3/4″ROTATION RESISTANT 15×K
STRAND, GRADE 1960）
Weight: 160kg/100m (1.1LBS/FT) Minimum breaking strength: 31.1T (30.61TONS)
1.2 TIRE INFLATION CHART
Table 01 – 2 Tire Inflation Chart
RECOMMENDED TIRE PRESSURE
TIRE SIZE STATIONARY
CREEP
21/2MPH
TRAVEL
26.50-25-32PR
580kpa（85 PSI） 580kpa（85 PSI） 450kpa（65 PSI）
