Unscrew the self-aligning bearing of the axis that holds the lower long belt to be
replaced. Use a wrench or pliers to hold the nuts of the screws.
UNSCREWING THE SELF-ALIGNING BEARING, PART 2
Unscrew the other self-aligning bearing of the axis that holds the lower long belt to be
replaced. Use a wrench or pliers to hold the nuts of the screws.
LOWER LONG BELT REMOVAL
