zortrax M200 Manual

12
PREPARE YOUR PRINTER TO WORK
1. Attach power supply cable.
2. Mount lament guide.
3. Mount lament spool holder.
4. Mount spool of the Z-ABS™ on the spool holder. Spool should
rotate anti-clockwise. Lead the lament through the lament
guide to the printer.
PREPARATION FOR FIRST USE
CAUTION! Always connect the power cable into
a grounded outlet.

zortrax M200 Specifications

General

Build Volume	200 x 200 x 180 mm
Layer Resolution	90-400 microns
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Connectivity	SD card
Software	Z-Suite
Operating System	Windows, macOS
Frame	Aluminum
Printing Speed	up to 100 mm/s
Heated Bed	Yes
Bed Temperature	up to 110°C
Nozzle Temperature	up to 380°C
Power Consumption	300 W
Technology	FDM
Supported Materials	Z-ABS, Z-ULTRAT, Z-HIPS, Z-GLASS, Z-PETG, Z-ESD
Power Supply	100-240 V, 50/60 Hz
Dimensions	345 x 360 x 430 mm
Weight	13 kg
