zortrax M200 Manual

TROUBLESHOOTING
37
PROBLEM SOLUTION
No power
Check if power cord is connected rmly
Hotend is not heating up
Check if wide strip connector is plugged rmly – if hotend is not heating up, please
contact our Support Center
Platform is not heating up
Check if 2 platform connectors are plugged rmly – if they are but platform is still not
heating up, please contact our Support Center
Printer stops working during printing process
Check:
• if printer is connected to the power supply;
• if there wasn’t any power outage;
• if the lament spool rotate freely;
• if the lament is not nished;
• if the nozzle is not blocked
Nozzle does not provide lament or provides it discontinuously
Please go to support.zortrax.com
Printed models are deformed
Please go to support.zortrax.com
Printer has troubles printing small models
Increase speed fan. If that won’t help,
please go to support.zortrax.com
Nozzle hits model when printing / black spots on a model
Please go to support.zortrax.com
Model lifts on platform during printing process
Please go to support.zortrax.com
Fan stopped working
Please go to support.zortrax.com
The printer is making strange noises while printing (clicking)
Please go to support.zortrax.com
The LCD display is not working correctly
Please go to support.zortrax.com
Other
Please go to support.zortrax.com

zortrax M200 Specifications

General

Build Volume	200 x 200 x 180 mm
Layer Resolution	90-400 microns
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Connectivity	SD card
Software	Z-Suite
Operating System	Windows, macOS
Frame	Aluminum
Printing Speed	up to 100 mm/s
Heated Bed	Yes
Bed Temperature	up to 110°C
Nozzle Temperature	up to 380°C
Power Consumption	300 W
Technology	FDM
Supported Materials	Z-ABS, Z-ULTRAT, Z-HIPS, Z-GLASS, Z-PETG, Z-ESD
Power Supply	100-240 V, 50/60 Hz
Dimensions	345 x 360 x 430 mm
Weight	13 kg
