zortrax M200 Manual

14
PREPARATION FOR FIRST USE
Select “Maintenance” option from the mean menu.
Now select “Platform auto-calibration” option.
Tighten 3 pcs screws on the bottom of the platform.
Zortrax M200® is checking level of the back part of the platform.
Zortrax M200® is showing information which screw should be tighten and which should be loosen.
Follow the instruction on the display.
AUTO-CALIBRATION

zortrax M200 Specifications

General

Build Volume	200 x 200 x 180 mm
Layer Resolution	90-400 microns
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Connectivity	SD card
Software	Z-Suite
Operating System	Windows, macOS
Frame	Aluminum
Printing Speed	up to 100 mm/s
Heated Bed	Yes
Bed Temperature	up to 110°C
Nozzle Temperature	up to 380°C
Power Consumption	300 W
Technology	FDM
Supported Materials	Z-ABS, Z-ULTRAT, Z-HIPS, Z-GLASS, Z-PETG, Z-ESD
Power Supply	100-240 V, 50/60 Hz
Dimensions	345 x 360 x 430 mm
Weight	13 kg
