Zotac ZBOX

3
Quick Start Guide
EN
Front panel
1. Headphone/Audio Out
jack
2. Microphone jack
3. Memory card reader
(MMC/SD/SDHC/
SDXC)
4. USB 3.0 port
5. WiFi LED (optional)
6. Hard drive LED
7. IR Receiver
8. Power button
Setting up your ZOTAC ZBOX
1. Select your ZOTAC ZBOX position
i. Place ZOTAC ZBOX sideways
ii. Install ZOTAC ZBOX on the stand
iii. Mount ZOTAC ZBOX to a monitor
2. Connect antenna for WiFi
3. Connect an optical S/PDIF output
4. Connect to a home network
5. Connect USB 3.0 devices
6. Connect a DVI, HDMI or VGA display
7. Connect a DisplayPort display
8. Connect power cable
9. Turn on the system
10. Install operating system
Status LED (optional)
System is on LED is on
System is off LED is off
System is in standby mode LED ashes slowly
Rear panel
1. WiFi antenna connector
2. Optical S/PDIF output
3. LAN (RJ45) ports
4. USB 3.0 ports
5. DVI-I port
6. DisplayPorts
7. Power input (DC19V)
1
i
ii
iii
2
3
4
5
6
9
7
8
1 2 3 4 6 75
1 2 3 4 5 6 7 8
