ZXHN H168N User’s Manual
14
Connection procedures
1 Power off the equipment before all the other devices
are connected.
2 Connect the network cables: Insert the RJ-45
Ethernet cable connector into the Ethernet interface of
the ZXHN H168N, and connect its other terminal to the
Ethernet adapter of the customer computers or ports of
other network devices.
3 Connect the splitter
The splitter has three interfaces, which are described as
follows:
 LINE: Connect the user telephone cable (RJ11
interface).
 MODEM (or DSL): Connect the DSL interface of
the ZXHN H168N.
 PHONE (or TEL): Connect the phone sets.
The installation process is as follows: Connect the LINE
interface of the ZXHN H168N to the MODEM(or DSL)
interface of the splitter using the RJ-11 telephone cable,
