ZXRAN V9200 Product Description
ZTE Confidential & Proprietary 29
3 Technical Specifications
3.1 Physical Specification
Table 3- 1 Physical Specification
Item
Value
Size (H x W x D) (mm)
88.4 x 482.6 x 370 (including mounting brackets)
88.4 x 445 x 370 (excluding mounting brackets)
Weight with full configuration
(kg)
8 – 20 (
may vary with the actual configuration
)
3.2 Capacity
Table 3- 2 Capacity of V9200
Mode
Capacity
GSM
216 TRXs
UMTS
48 CSs
LTE
90 20MHz Cells, DL 14.4 Gbps/UL 7.2 Gbps,
FDD LTE MM
15 32T32R 20MHz Massive MIMO Cells
TDD LTE MM
60 32T32R/64T64R 20MHz Massive MIMO Cells
TDD NR
30 32T32R/64T64R 100MHz Cells, DL 20 Gbps/UL 4 Gbps
Note: 1. The above table describes the maximum hardware capability. The actual capability is up to
the licenses configured. 2. The multi-mode capacity can be calculated according to the capacity of
the configured boards. 3. LTE can be FDD LTE or TDD LTE, where FDD LTE supports
2T2R/2T4R/4T4R and TDD LTE supports 2T2R/4T4R/8T8R.
