Operating Manual – Folding bike with electric drive up to 250 W
16.07.2021 REV 2.1
56
 Pushing and starting aid
The pushing and starting aid is only an assistant. It should not be
assumed that you can travel forward with the starting aid com-
pletely without pedalling.
To start the pushing and starting aid, press and hold the button. The bike travels at a maximum
speed of 6 km/h. The pushing and starting aid remains active as long as you hold the button
pressed. The pushing and starting aid switches off automatically when you release the button.
 Battery and charge capacity indicator
Full charge state
Half charge state
Low charge state
Very low charge state
The battery charge capacity indicator on the display shows you the battery status in five levels.
When the battery is fully charged, the word “FULL” appears at the top left of the display. If the capac-
ity slips into undervoltage, this is indicated by the letter “E” next to the battery symbol and the LCD
indicator starts to flash.
If this is the case, the battery should be charged as soon as possible.
 Error code information
If a problem occurs with the electric drive, the controller or an
electrical component, this is indicated by an error code in the
display. If an error code is displayed, the system or component
concerned must be checked accordingly.
