Internal secured RFID Card Reader 13.56 MHz
The (Part No. 9151019) is used for reading RFID Internal RFID Card Reader 13.56 MHz
card Ids in the 13.56 MHz band, NFC supported. This module is intended for mounting
into the model 9151101RPW, 9151101CRPW, 9151101CHRPW, 9151102RW, 2N IP Force
®
9151102CRW a 9151102CHRW. These models have an window, which is necessary for
antenna operation. If the Internal RFID Card Reader is installed, it is not possible to
install the Additional Switch.
Function:
The Internal RFID Card Reader adds two logical inputs, two additional 2N IP Force
®
switches and a tamper switch to the basic unit.2N IP Force
®
The purpose of the tamper switch is to signal any unauthorised opening of the
intercom (to prevent a theft, e.g.). It is recommended to use the tamper switch.
Tip
FAQ: Tamper switch – How to install it into the 2N IP Force
®
Specifications:
Card reader
Operating frequency: 13.56 MHz
Minimum reading distance: 30 mm above cover2N IP Force
®
Compatible with cards (optionally card serial number or PAC ID is read):
ISO/IEC 14443A Mifare Classic 1k & 4k, DESFire EV1, Mini, Plus S&X,
Ultralight, Ultralight C
ISO/IEC 14443B CEPAS, HID iCLASS
JIS X 6319 Felica
