JIS X 6319 Felica
ISO/IEC 18092 SmartPhone with NFC/HCE support, since Android version
4.3
Relay output
Switching contact
30 V / 2 A AC/DC
Active output
9 to 12 V / 700 mA transistor switched output. Depends on power supply (PoE:
9 V or power supply voltage minus 1 V).
Logical inputs
Active mode – requires external voltage (JP2 jumper OFF)
U -ON = min +2.5 V
IN
U -OFF = max +1.5 V
IN
U max = +48 V
IN
I (U +48 V) = max 1 mA
IN IN
Passive mode – requires external contact only (JP2 jumper ON)
U = approx. 8.3 V
IN1
U = approx. 8.3 V
IN2
I = approx. 0.5 mA
LOOP
Signalling output
Internal red LED under reader window
PWR
For external RFID card reader
Out: 9 to 12 V / 350 mA depends on power supply
WIEGAND interface
Off/Input/Output (as programmed)
