The acoustic signal indicates mode switching.
Wait until the device is restarted automatically.
Caution
The 1, 1, 1, 2, 2, 3 sequence must be entered within 30 seconds after the
first sound signal for security reasons. The inter-digit delay may be 2 s at
most.
The device will have the following network parameters after restart:
IP address – 192.168.1.100
Network mask – 255.255.255.0
Default gateway – 192.168.1.1
Dynamic IP Address Setting for 4-button models
Follow the instructions below to enable automatic getting of network parameters
from the DHCP server:
Connect to the power supply (or, disconnect and reconnect it if 2N IP Force
®
already connected).
Wait for the first acoustic signal
Press buttons 2, 1, 1, 2, 2, 3 sequentially.
The acoustic signal indicates mode switching.
Wait until the device is restarted automatically.
