5.1 List of Status Codes
Plug-In Boards
Board Types
NONE – (no board)
VIP172 – VoIP board
CPU – (CPU board is not displayed)
PRI 132 – 2PRI port NT/TE board
GSMxxx – 2GSM module + (2SIM board)
INIT – HW board reset and init of respective SW parts in progress (follow
OK/CHECK)
ERROR – Board in wrong slot or defective board HW (follow board reset)
POWER – Only upon system power on or AT!Bxx=RESET command (follow
DETECT)
OK – Rest status, HW is working on board (full operation) (follow DISC)
UNDEF – Empty slot (follow DETECT)
CHECK – Board firmware check (AUX only) (follow ERASE)
ERASE – Board firmware erasing (AUX only) (follow PROF)
PROG – New board firmware loading (AUX only) (follow OK)
DETECT – New board plug-in detected (follow INIT)
DOWN – Frozen status, HW is working on board but no new calls are started
(follow board reset)
MODEM0 – Parameter S80 sent to modem (AUX only) (follow MODEM1)
MODEM1 – Parameter S81 sent to modem (AUX only) (follow OK)
DISC – Board plug-out detected (follow UNDEF)
ISDN Layer Statuses
ISDN Layer 2
DEACT – Deactivation – no signal received
ACTIVE – Activation – full synchronisation achieved (frame,multiframe,crc)
SIGNAL – Signal received – no synchronisation
SYNC – Signal received – only partial synchronisation (frame)
ISDN Layer 2 (Name and Name According to Q.921)
NOTEI – TEI Unassigned
AWTEI – Assigned Awaiting TEI
AWTEST – Establish Awaiting TEI
OKTEI – TEI Assigned
AWEST – Awaiting Establishment
AWREL – Awaiting Release
OKEST – Multiple Frame Established
TIMREC – Timer Recovery
