Directional Antenna Connection Cable
2N offers you a special low-attenuation cable in variable lengths. The cable terminating
connectors are of the N type.
Type – H1000 PE coax cable
Impedance 50Ω–
Operating frequency 5 – 2150 MHz–
Used connectors N type (female)–
Cable size 10.3mm–
Operating temperature 40°C to +80°C– −
Total weight 120 g/m–
Minimum installation temperature –5°C–
Minimum static bend radius 75mm–
Attenuation at 860MHz 14.1dB / 100m–
Attenuation at 1000MHz – 15.3dB / 100m
Attenuation at 1750MHz – 21.3dB / 100m
Attenuation at 2050MHz – 23.4dB / 100m
