Others
Text of SMS at no answer – edit the text of the SMS to be sent to the calling
party in case of no answer (if the function is active). The %N string will insert the
CLIP received from VoIP in the SMS text.
Text of SMS for all calls – complete this parameter to make the GSM gateway
send SMS to every called party regardless of whether or not the call was
successfully connected. The %N string will insert the CLIP received from VoIP in
the SMS text.
Save received SMS to – select the storage for received SMS messages.
SIM card identification – set the SIM Id (IMSI/SCID) to be entered in the CDR.
Disable CLIP from GSM/UMTS to VoIP – enable/disable resending of the CLIP
from GSM to VoIP.
Reject call with CHLD – enable rejection of incoming calls from GSM/UMTS via
AT+CHLD (subscriber busy) instead of standard ATH.
Network registration timeout [min] – set the timeout after which the module
must log in. The login process will be restarted after this timeout.
GSM Group Assignment
Here you can assign the GSM/UMTS modules to groups. You can assign incoming and
outgoing calls separately using the parameters below.
GSM Outgoing Groups
– dMode of switching SIM card efine how to use the SIM cards in the selected
GSM group:
– the SIM cards in position # will only be used in the selected GSMSIM #
group. In this case, the and Maximum called minutes Disconnect call
parameters are disabled.
– the SIM card will be switched according to the Time of useBy time
parameter and call timer limitations.
– the SIM card will be switched randomly at defined timeRandom
intervals and according to call timer limitations.
– the SIM card will be switchedBy time and limit; then SIM card 1
according to the Time of use parameter and call timer limitations. When all
SIM cards on a selected wireless engine are discharged, the system will
switch the wireless engine back to the SIM card in position 1.
– the SIM card will be switchedRandom and by limit; then SIM1
randomly at defined time intervals and according to call timer limitations.
When all SIM cards on a selected wireless engine are discharged, system
will switch the wireless engine back to the SIM card in position 1.
– Define the number ofLast searched SIM (8 – all SIM will be searched)
SIM holder positions to be checked for SIM by the gateway after the GSM / UMTS
board start/restart. The SIM card holders that were not tested have the (undef)
status in the diagnostics window of the web interface.
Delay for CONNECT [s] – define a delay before sending information on the
connected call after receipt from GSM.
Minimum ring duration to send SMS at no answer [s] – set the minimum
ringing time for an outgoing call to GSM/UMTS before the SMS at no answer is
sent.
